ST9300F 11.6inch Desktop Small POS
Dual OS Options:
- Windows: Intel Celeron J6412 (up to 2.6GHz), Win10/11 supported
- Android: Rockchip RK3568/RK3566, Android 11, 13 supported
Performance:
- RAM: 4-16GB (Windows) / 2-8GB (Android)
- Storage: 128-512GB (Windows) / 32-64GB (Android)
Display:
- 11.6″ HD screen (1366×768/1920×1080)
- 10-point capacitive touch
Key Features:
- Rugged Design: Metal+plastic casing, only 2kg
- Rich I/O:
- Windows: 4×USB3.0 + 2×USB2.0 + HDMI + Ethernet
- Android: 6×USB2.0 + SIM/SD slots
- Wireless: WiFi & Bluetooth built-in
- Expandable: Optional RFID/NFC/magnetic card reader
Applications: Ideal for retail POS, industrial control, self-service terminals, and other touchscreen solutions.
Certifications: CE, FCC, ROHS certified for quality assurance.
Note: Custom colors (black/white) and special functions available upon request.
Feature
1. 11.6″ Touchscreen – 10-point responsive touch for fast, accurate operation
2. Slim & Portable – Mini size perfect for countertops or mobile use
3. Quiet Performance – Fanless design means zero noise
4. Wireless Options – Choose WiFi, Bluetooth or add a speaker
Ideal for: Retail shops, cafes, food trucks and mobile businesses needing a space-saving solution.
Excellent Performance
Easy to Operate
Using high-performance Intel processor,
the POS hardware can be integrated with a choice of
different Intel processors for enhanced performance
to run today’s demanding POS applications.
IO Port
Packing & Shipping
Application
Contact US
Make Cashiering Easier
- Tel: +86 15019090919
- Email:[email protected]
- Room 203, Building 2, No. 25, Daxin Road, Gedi, Nancheng Street, Dongguan, Guangdong, China
Specification
| Specification | Windows | Android |
|---|---|---|
| Model Number | ST9300F | |
| CPU | Intel Celeron Processor J6412(1.5M Cache, up to 2.60GHz) |
RK3568 Quad-core ARM Cortex A55 up to 1.8GHz/2.0GHz RK3566 Quad-core cortex A55 up to 2.0GHz |
| Memory | 4GB, 8GB, 16GB | 2GB, 4GB, 8GB |
| Hard Disk | 128GB, 256GB, 512GB | 32GB, 64GB |
| Ethernet | 10M/100M/1000M Self-adaption | 1wifi&BT module, 1 RJ45 Ethernet port |
| I/O Port | DC*1, HDMI*1, COM*1, RJ50*1, RJ12*1, USB3.0*4, USB2.0*2, Audio*1 | DC*1, RJ11*1, COM*1, AUDIO*1, SD*1, SIM*1, USB2.0*6, LAN*1 |
| Display Screen | 11.6inch True Flat Screen(16:9) | |
| Resolution | 1366*768/1920*1080 | |
| Touch Screen | 10 Points Capacitive Touch | |
| OS Support | Windows10/11, Linux | Android 11, 13 |
| Housing Material | Metal & Plastic | |
| Power Supply | 12V, 5A | |
| Warranty | 3 Years | |
| Color | Black | |
| Package Size | 37cm*27cm*18cm(2KG) | |
| Certification | ROHS, CE, FCC, etc. | |
| Option |
Built-in: Wifi, Bluetooth, Loudspeaker Reader: MSR/RFID/NFC/IBUTTON |
|
*product specifications and model configurations are subject to change and may vary by global region.
