ST9100F 21.5″ Self Service Kiosk
Display & Durability:
- 21.5″/23.8″ Full HD (1920×1080) capacitive touchscreen
- 10 – point multi – touch with ≥4mil readability
- IP52 rated metal housing
- Motion tolerance >2m/s for stable operation
Connectivity & Expansion:
- Dual – band WiFi 802.11b/g/n & Bluetooth
- Gigabit Ethernet (10/100/1000M self – adaptive)
- Multiple I/O ports for peripheral connections
- Optional RFID/NFC reader integration
Industrial Features:
- 12V/7A power supply for stable operation
- Supports POS terminal and invoice printer holders
- Optional 80mm thermal printer with auto cutter
- 2D area – imaging scanner available
Applications: Ideal for retail POS, industrial automation, warehouse management, and self – service kiosks requiring robust performance and reliable touch operation.
Feature
- The device adopts the core decoding technology, millions of pixels, can quickly read all kinds of commodities / screen bar code;
- High motion tolerance, bringing hand-waving reading experience;
- High protection level, able to cope with various environments.
Excellent Performance, Easy to Operate
Fast Intel® Processors – Choose powerful i3/i5 or energy-efficient J6412/N100 chips for smooth performance
Handles Heavy Workloads – Runs multiple POS apps, self-service kiosks and digital menus without lag
Flexible Configuration – Select the right processor for your business needs (retail/restaurant/hospitality)
Energy Efficient – Lower power consumption models available for 24/7 operation
Versatility in Mounting Options
Waterproof, Oilproof, Dustproof
Damage Resistance, Waterproof, Oilproof, Dustproof. This allows the cash register to be used in more scenarios. For example: kitchens with lots of oil, drinking establishments with lots of water, etc.
10 Point Ture Flat Capacitive Touch Screen
More I/O Interface.Than Ever.
Windows: DC-in*1,HDMI*1, VGA*1,USB2.0*2,LAN*1, USB3.0*2,Audio*1Hub(COM*2,USB2.0*2)
Android: DC*1, RJ12*1, COM*1,Audio*1,SD*1, SIM*1, USB2.0*4, LAN*1Hub(uSB2.0*2)
Customized I/O interface is available to meet different business needs.
Well-Suited for…
This versatile self-service kiosk provides complete automation solutions for modern businesses. The intuitive touchscreen system handles multiple functions including food ordering in restaurants, fast checkout in retail stores, product scanning in supermarkets, and ticket collection at entertainment venues. Designed for simplicity, it features clear user guidance and quick payment processing to improve customer flow. The durable kiosk operates 24/7, significantly reducing queues and staff workload while maintaining reliable performance. Ideal for quick-service restaurants, grocery chains, cinemas, and transportation hubs, this all-in-one self-service solution enhances efficiency across food service, retail, and entertainment industries with its user-friendly interface and robust construction.
Self-service Ticket Collection
Self-service Code Scanning
Self-service Cashier
Self-service Order
Overview
Specification
*product specifications and model configurations are subject to change and may vary by global region.
| Specification | ||
|---|---|---|
| Windows | Android | |
| Model Number | ST9100F | |
| CPU |
Intel Core i5 Dual Core (the 8th, 10th, 11th, 12th gen) Intel Core i3 Dual Core (the 10th, 11th gen) Intel Celeron Processor J6412(1.5M Cache, up to 2.60GHz) Intel Processor N100(6M Cache, up to 3.40GHz) |
Rk3568 Quad core ARM Cortex A55, Neon and FPU |
| Memory | 8GB, 16GB | 4GB |
| Hard Disk | 128GB, 256GB, 512GB | 32GB, 64GB, 128G |
| Ethernet | 10M/100M/1000M Self - adaption | 1wifi&BT module, 1 RJ45 Ethernet port |
| I/O Port | DC - in*1,HDMI*1, VGA*1,USB2.0*2,LAN*1, USB3.0*2,Audio*1Hub(COM*2,USB2.0*2) | DC*1, RJ12*1, COM*1,Audio*1,SD*1, SIM*1, USB2.0*4, LAN*1Hub(uSB2.0*2) |
| Display Screen | 21.5/23.8inch 10 Points Capacitive True Flat Touch Screen | |
| Resolution | 1920*1080 | |
| Touch Screen | 10 Points Capacitive Touch | |
| Motion tolerance | ＞2M/S | |
| Readability | ≥4Mil | |
| OS Support | Windows7/10/11, Linux | Android 11, 13 etc. |
| Housing Material | Metal | |
| Power Supply | 12V, 7A | |
| Warranty | 3 Years | |
| Color | White (Customizable) | |
| Package Size | 93*48*36.5cm（23.8inch） 88*45*36.5cm（21.5inch） | |
| Certification | ROHS, CE, FCC, etc. | |
| Option |
Holder: POS Terminal Holder/Invoice Printer Holder Built - in: WIFI/ Bluetooth/Loudspeaker Reader: RFID/ NFC |
|
| Printer | 80mm thermal printer with auto cutter | |
| Scanner | 2D, Area - imaging scanner | |
