NEW ARRIVAL
ST8500 POS Terminal
Next-generation checkout technology designed for efficiency and reliability.
- Tool-free upgrades (1 screw only) for maximum flexibility
- Fanless motherboard for silent, stable operation
- Modular structure tailored to your retail needs
Make Cashiering Easier
Product Features
Advanced features designed to enhance your retail operations and customer experience
01
High-Brightness & Ultra-Slim LED Screen
- 0.9cm ultra-narrow bezel, built for wholesale POS markets
- 350 cd/㎡ brightness for clear readability in well-lit stores
- 270° rotatable screen with ergonomic design
02
Fanless Motherboard for Silent Operation
- Whisper-quiet, reliable performance in factory-direct POS
- Passive cooling reduces CPU stress and extends lifespan
- Full aluminum-alloy chassis enhances heat dissipation
03
Tool-Free Upgrades
- Battery, HDD, memory replaceable with 1 screw only
- Reduces return rates and simplifies local after-sales
- Supports two M.2 SSDs for faster performance
04
Modular Structure
- Tailor builds to market needs with detachable modules
- Optional VFD220, MSR, and customer display for upsells
- Supports 9.7"/11.6" independent displays + third monitor
05
Optional Interface
- Expandable USB and powered OPOS ports for flexible integration
- Color-coded power (Red 24V×1, Blue 12V×2) + RJ12 OPOS ports
- Supports more peripherals and scenarios
06
Foldable Base Design
- Compact foldable base reduces shipping volume/weight
- “Unfold-and-use” convenience, no complex assembly
- Boosts competitive edge in pricing, delivery, and deployment
Technical Specifications
| Specification | Details |
|---|---|
| CPU |
Intel® Core™ i3-1215U (10M Cache, up to 4.40 GHz) Intel® Core™ i5-1235U (12M Cache, up to 4.40 GHz) Intel® Alder Lake-N N95 (6M Cache, up to 3.60 GHz) |
| Memory | 8GB / 16GB / 32GB |
| Hard Disk | 128GB / 256GB / 512GB (2 × M.2 Key-M 2280) |
| Ethernet | 10M / 100M / 1000M Self-adaption |
| OS Support | Windows10/11, Linux, etc. |
| Display Screen | 15.6" True Flat Screen (16:9) |
| Resolution | 1920*1080 |
| Touch Screen | 10 Points Capacitive Touch |
| I/O Port | USB2.0×4, DC-IN×1, USB3.0×2, RJ11×1, LAN×1, COM×2, Audio×1 |
| Housing Material | Metal |
| Power Supply | 12V, 5A / 12V, 7A |
| Color | Black / White (Customizable) |
| Package Size | 43.5 × 16.5 ×41.5 cm（7.5KG） |
| Certification | ROHS / CE / FCC |
| Customer Display | 11.6" / 15.6" |
| Built-In | Wi-Fi / Bluetooth / Loudspeaker |
| Reader | MSR / RFID / NFC / iBUTTON |
Product Gallery
Configuration
Entry-Level
N97/8GB RAM/128GB
SSD/WiFi/Speaker
Mid-Tier
i3-1215U/8GB RAM/128GB
SSD/WiFi/Speaker
High-Performance
i5-1235U/8GB RAM/128GB
SSD/WiFi/Speaker
