Industrial Fanless Embedded Computer with Intel® Tiger Lake i7/i5/i3 CPU, Dual 2.5G LAN, Triple Display, 9–36V Wide Voltage Input
-
High-Performance Processing
Powered by Intel® 11th Gen Tiger Lake UP3 processors (i3/i5/i7 options), this fanless embedded PC delivers strong computing power with excellent energy efficiency—ideal for demanding industrial environments. -
Rich I/O and Display Options
Equipped with dual Intel® 2.5GbE LAN ports, up to 8 USB ports, 2 configurable COM ports (RS232/422/485), and triple display outputs (HDMI, DP, VGA), supporting resolutions up to 4K. Perfect for multi-screen monitoring and control. -
Industrial-Grade Reliability
Designed with a rugged aluminum + SGCC enclosure, wide voltage DC input (9–36V), and protection against short-circuit, overvoltage, and overcurrent. Supports features like watchdog timer, auto power-on, network wake-up, and one-key OS recovery for uninterrupted industrial operation.
Industrial Fanless Embedded Computer with Intel® Tiger Lake i7/i5/i3 CPU, Dual 2.5G LAN, Triple Display, 9–36V Wide Voltage Input
Better POS, Better Business
Feature
The GF-603EI-S is a compact, fanless industrial embedded PC engineered for reliability in harsh environments. Powered by Intel® Celeron®/Core™ i3/i5/i7 Tiger Lake UP3 CPUs, it delivers robust computing with low power consumption. This unit supports up to 64GB DDR4 memory, features dual Intel 2.5GbE LAN ports (i226-LM & i226-V), and supports multiple storage options, including M.2 NVMe SSD and a 2.5″ SATA drive bay.
Ideal for industrial automation, smart factories, and IoT edge applications, the GF-603EI-S offers rich I/O options, including 8 USB ports, 2 COM ports (RS232/422/485 switchable), GPIO, and audio interfaces. Its triple independent display outputs (HDMI, DP, VGA) support high-resolution video output up to 4K.
Designed with a rugged aluminum + SGCC chassis, it supports wide voltage input (DC 9–36V) with protection against short-circuit, overvoltage, and overcurrent. Additional industrial features include watchdog timer, auto power-on, wake-on-LAN, scheduled boot, and one-key OS recovery.
Overview
| Product Specifications | |
|---|---|
| CPU | Onboard Intel® 11th Gen Tiger Lake UP3 i3/i5/i7 Processor |
| Memory | 2× DDR4 SO-DIMM slots, up to 64GB, 3200MHz |
| Graphics | Intel® HD Graphics VGA: 1920×1200@60Hz HDMI: 4096×2160@24Hz DP: 4096×2304@60Hz |
| Storage | 1× M.2 M-Key 2280 (NVMe supported) 1× Internal 2.5" SATA HDD/SSD bay (SATA 3.0) |
| Expansion | 1× M.2 B-Key (2242/2252, PCIeX1 + USB3.0/2.0) 1× M.2 E-Key (2230, PCIeX1 + USB2.0) 1× PCIe 8x slot (wired as PCIe 1x) 1× SIM slot 1× LPT (2×13Pin Wafer, PH=2.0mm) |
| LAN | 2× Intel® 2.5GbE (i226-LM + i226-V) |
| USB Ports | Front: 2× USB3.0, 2× USB2.0 Rear: 2× USB2.0, 1× USB3.0 + 1× USB2.0 |
| COM Ports | 2× DB9, BIOS selectable RS232/422/485, pin #9 with 5V/12V optional |
| Audio | 1× Line-out, 1× Mic-in |
| GPIO | 1× 2×9-pin Phoenix connector (8DI/8DO) |
| Display Outputs | 1× HDMI, 1× DP, 1× VGA (triple display supported) |
| Power Input | 1× 2-pin Phoenix connector, DC 9–36V (with OVP, OCP, SCP protection) |
| Power Functions | Auto Power On, Watchdog Timer, Wake on LAN, Scheduled Boot, OS Recovery |
| Indicators & Switches | Power Switch, Reset Switch, Remote Switch, Power LED, HDD LED |
| Construction | Aluminum extrusion + SGCC steel, sandblasted + powder-coated |
| Dimensions | 235 × 202.5 × 67 mm (excluding ears) 245.6 × 202.2 × 70 mm (with mounting ears) |
| Weight | Approx. 1.2 kg |
| Operating Environment | Operating Temp: -20°C to 60°C Humidity: 5%–95%, non-condensing |
| Storage Environment | Storage Temp: -20°C to 85°C Humidity: 5%–95%, non-condensing |
