Touch Screen POS Terminal Supplier | ST8500 with MSR

PRODUCT FEATURES

Model: ST8500 touch screen pos terminal

Housing Material: Full-metal die-cast

Display: 15.6-inch (Optional 15-inch)

CPU: i3-1215U, i5-1235U, N95

RAM: 8GB, 16GB, 32GB

HDD: 128GB, 256GB, 512GB (2 × M.2 Key-M 2280)

Supported OS: Windows / Linux / Android

External Cash Register Peripherals: MSR, Fingerprint, 11.6-inch/15.6-inch Customer Display

Certification: CE, FCC, ROHS, etc.



ST8800 POS system new arrival

NEW ARRIVAL

Model: ST8500

  • Hard drive and memory can be replaced by removing 1 screw
  • Only 4 screws are needed to remove the back cover of the machine
  • The IO interface is customized according to European and American style
GET A Quote

Product Features

With reliable supply chains and certified production standards, the ST8500 empowers distributors to deliver premium ODM touchscreen POS terminal solutions for bars and restaurants with full confidence.

High-Brightness & Ultra-Slim LED Screen

📏 High-Brightness & Ultra-Slim LED Display

  • Engineered for the Touch display POS system market; ultra-narrow bezel paired with a sleek 9mm thickness.
  • 350cd/㎡ brightness guarantees sharp visibility—perfect for touch screen point of sale terminal setups in brightly lit bar and restaurant environments.
  • 270° swivel screen boosts operator comfort, enhancing usability during peak dining and drinking hours.

💨 Fanless Motherboard for Silent Operation

  • Custom fanless motherboard delivers quiet, stable performance for the touch screen pos terminal designed for bars and restaurants.
  • Passive cooling lowers CPU strain and prolongs service life—suited for bar and restaurant operations demanding non-stop uptime.
  • Aluminum-alloy frame improves heat dispersion, reducing malfunctions and post-sales service needs.
Fanless Motherboard for Silent Operation
Tool-Free Upgrades

⚙ Tool-Free Upgrades

  • Battery, HDD, and memory replacement requires just one screw removal—accelerating maintenance for wholesale OEM ODM touchscreen POS terminal orders.
  • Cuts return rates and streamlines after-sales support; end-users can manage basic replacements independently.
  • Supports dual M.2 SSDs to deliver faster speeds and versatile storage configurations.

🔧 Modular Structure

  • Modular design allows distributors to customize Touch display POS system setups for any bar or restaurant scenario.
  • Detachable modules include MSR and customer display, enabling easy upgrades or retrofits.
  • Optional 11.6"/15.6" secondary displays, plus compatibility with a third external monitor for professional configurations.
Modular Structure
Optional Interface

🔌 Optional Interface

  • Expandable USB and powered OPOS ports—ideal for touch screen pos terminal installations needing flexible peripheral connectivity.
  • Color-coded power ports: Red = 24V×1, Blue = 12V×2; plus RJ12 OPOS ports for easy setup.
  • Comprehensive I/O options support more devices, helping distributors secure venue-specific projects.

📦 Foldable Base Design

  • Foldable base reduces shipping volume and weight—lowering logistics costs for bulk touch screen point of sale terminal orders.
  • “Unfold-and-use” setup eliminates complex assembly, perfect for fast bar and restaurant deployments.
  • Enhances distributors’ competitiveness in pricing, delivery speed, and installation efficiency.
Foldable Base Design

Why Choose Matsudapos?

  • Full OEM/ODM Customization

  • 24/7 Quick Response Support

  • Professional Sales Team

  • Strict Quality Control

  • Competitive Cost Advantage

  • Dealer Protection Policy

Learn more about what Matsudapos can do for you.

Join our mailing list for more information about how Matsudapos’s solutions can serve your entire business.

*This information may be transcribed, used, and stored by third parties in accordance with our Privacy Policy.

Technical Specifications

ST8500 POS Specification

Specification Details
CPU Intel® Core™ i3-1215U (10M Cache, up to 4.40 GHz)
Intel® Core™ i5-1235U (12M Cache, up to 4.40 GHz)
Intel® Alder Lake-N N95 (6M Cache, up to 3.60 GHz)
Memory 8GB 16GB 32GB
Hard Disk 128GB 256GB 512GB (2 × M.2 Key-M 2280)
Ethernet 10M / 100M / 1000M Self-adaption
OS Support Windows 10/11, Linux, etc.
Display Screen 15.6" True Flat Screen (16:9)
Resolution 1920×1080
Touch Screen 10 Points Capacitive Touch
I/O Port USB2.0×4, DC-IN×1, USB3.0×2, RJ11×1, LAN×1, COM×2, Audio×1
Housing Material Metal
Power Supply 12V, 5A / 12V, 7A
Color Black / White (Customizable)
Package Size 43.5 × 16.5 × 41.5 cm (7.5KG)
Certification ROHS CE FCC
Options
Customer Display 11.6“ 15.6”
Built-in Wi-Fi Bluetooth Loudspeaker
Reader MSR RFID NFC IBUTTON

Pricing

Configuration
Specs
Recommendation Level
Entry-Level
N95 / 8GB RAM / 128GB SSD / WiFi / Speaker
❤❤❤❤
Mid-Tier
i3-1215U / 8GB RAM / 128GB SSD / WiFi / Speaker
❤❤❤❤
High-Performance
i5-1235U / 8GB RAM / 128GB SSD / WiFi / Speaker
❤❤❤❤❤

FAQ

Q1: How much does a POS system cost?

The price depends on your configuration choices such as motherboard, memory, storage, and I/O ports, as well as any customization and order quantity. Please contact us directly for a tailored quotation.

Q2: This is my first time importing POS equipment in bulk. What should I do?

Simply contact us. Our sales team will guide you step by step through the entire process. If needed, we can provide door-to-door service from production to delivery.

Q3: Are you a real manufacturer?

Absolutely. You are welcome to visit our factory at any time. Alternatively, we can arrange a live video call to show you our production facilities.

Q4: What after-sales support do you provide?

We offer 3 years warranty on POS devices. Our professional engineers are available for remote support to solve any technical issues quickly.

Q5: What is your typical lead time?

Samples: around 7 days.
Mass production: around 30 days, depending on customization and order volume.

Q6: What payment methods do you accept?

We accept T/T, L/C, PayPal, and also support ordering via Alibaba International. For other payment options, please contact us directly.

MatsudaPOS and the Environment

Made with 35% recycled material by weight.

Manufactured with 45% renewable electricity.

Ships in 100% biodegradable materials.
