15″ & VFD & MSR White Retail POS System for Small Business
PRODUCT FEATURES
Model: ST9800 retail pos system for small business
Housing Material: Full-metal die-cast
Display: 15inch Capacitive Touch Panel 1024*768
Supported OS: Windows/ Linux/ Android
Supported Customer Display: 9.7inch, 12inch, 15inch
Product Overview
Technical Specifications
ST9800 Product Specification Sheet
| Specification | ||
|---|---|---|
| Windows | Android | |
| CPU |
Intel Processor N97 (6M Cache, up to 3.60 GHz) Intel Processor N100(6M Cache, up to 3.40GHz) Intel Celeron Processor J4125(4M Cache, up to 2.70GHz) Intel Celeron Processor J6412(1.5M Cache, up to 2.60GHz) Intel Core i3 Dual Core (the 10th, 11th gen) Intel Core i5 Dual Core (the 8th, 10th, 11th, 12th gen) |
RK3568 Quad-core ARM Cortex A55 up to 1.8GHz/2.0GHz |
| Memory | 4GB, 8GB, 16GB | 4GB, 8GB |
| Hard Disk | 128GB, 256GB, 512GB | 32GB, 64GB |
| Ethernet | 10M/100M/1000M Self-adaption | 1wifi&BT module, 1 RJ45 Ethernet port |
| I/O Port | LINE-OUT*1, Type C*2, DC-IN*1, USB3.0*2, RJ11*1, LAN*1, COM*1 | DC*1, RJ11*1, COM*2, USB*6, SIM&SD*1, LAN*1, AU*2 |
| Display Screen | 15inch True Flat Screen (5:4) | |
| Resolution | 1024*768 | |
| Touch Screen | 10 Points Capacitive Touch | |
| OS Support | Windows10/11, Linux | Android11, Android13. |
| Housing Material | Metal | |
| Power Supply | 12V, 5A | |
| Warranty | 3 Years | |
| Color | Black/ White/ Silver/ Red/ Orange (Customizable) | |
| Package Size | 43cm*20cm*43cm 7.5KG (Single Screen) 47cm*27cm*45cm 9.5KG (Dual Screen) |
|
| Certification | ROHS, CE, FCC, etc. | |
| Option |
Customer Display: 9.7″/11.6″/12″/15″/15.6″ Built-in: WIFI/ Bluetooth/Loudspeaker Reader: MSR/ RFID/ NFC/ IBUTTON |
|
Intel Processor N100(6M Cache, up to 3.40GHz)
Intel Celeron Processor J4125(4M Cache, up to 2.70GHz)
Intel Celeron Processor J6412(1.5M Cache, up to 2.60GHz)
Intel Core i3 Dual Core (the 10th, 11th gen)
Intel Core i5 Dual Core (the 8th, 10th, 11th, 12th gen)
47cm*27cm*45cm 9.5KG (Dual Screen)
Built-in: WIFI/ Bluetooth/Loudspeaker
Reader: MSR/ RFID/ NFC/ IBUTTON
Key Features
Feature 1: All-metal Die-cast Casing
Industrial-Grade Metal Chassis: Reinforced alloy ensures lasting durability and a premium finish, ideal for high-demand small retail business environments.
24/7 Reliable Operation: Designed for non-stop performance in busy settings, perfect for a retail POS system for small business.
Advanced Thermal Control: Smart cooling maintains optimal temperature for sustained use.
High-Speed Transaction Processing: Easily handles peak sales volumes, making it one of the best retail POS systems for small business.
Universal Compatibility: Integrates smoothly with most retail POS systems for small business, enabling quick setup.
Feature 2: Modular Design
- Modular Expansion: Flexible architecture seamlessly integrates payment terminals, barcode scanners, and dual displays, offering a highly adaptable retail POS system for small business.
- Distribution-Optimized Inventory: Customizable computer configurations simplify stock management, making it one of the best retail POS systems for small business.
- Tool-Free Setup: Plug-and-play connectivity enables easy installation of MSR, RFID, and customer displays—ideal for any pos system for small retail business.
- Shipping-Friendly Packaging: Compact design lowers international freight costs and storage needs, perfect for global suppliers using retail POS systems for small business.
- Eco-Conscious Manufacturing: Incorporates recyclable materials and reduced packaging for sustainable point of sale operations.
Feature 3: Hidden Cable Management
- Advanced Cable Management: Bottom-port design neatly conceals cables, making it ideal for a clean and efficient retail POS system for small business.
- Clutter-Free Checkout: Reduces cable mess for a tidy and organized point-of-sale area, perfect for any pos system for small retail business.
- Elevated Brand Image: Sleek, wire-free design enhances modern appeal and customer experience, positioning it among the best retail POS systems for small business.
- Seamless Integration: Minimalist style blends effortlessly with various commercial decors and existing retail POS systems for small business.
Feature 4: 10-point Capacitive Touchscreen
- 10-Point Professional Touch: Multi-touch technology delivers precise control, enhancing efficiency for any retail POS system for small business.
- Commercial-Grade Protection: IP54 rating resists liquids, oil, and dust, ensuring reliable performance for retail POS systems for small business.
- High-Luminance Display: 500 nits brightness maintains clear visibility in various lighting, ideal for the best retail POS systems for small business.
- Military-Grade Durability: 7H hardened glass with oleophobic coating resists scratches and daily wear.
- Intuitive Touch Interface: User-friendly design with smooth response streamlines checkouts in a pos system for small retail business.
More POS Peripherals Options
MatsudaPOS offers versatile POS solutions for global partners. Our modular design allows for flexible setups, from compact single-screen terminals to advanced systems with payment readers, VFD modules, and dual displays (9.7″ or 15″). Ideal for retail, hospitality, and commercial use, our hardware is reliable, adaptable, and future-ready, meeting diverse needs worldwide.
Optional Peripheral Devices: MSR/VFD/Customer Display (9.7″, 12″, 15″)
Pleasant Success Stories
Successful Collaboration with Canadian Chain Store
In 2023, MatsudaPOS partnered with SIGMA Technology to deploy our POS systems across multiple retail chain stores in Canada. Thanks to the excellent performance and modern design of our cash register hardware, the solution was highly appreciated by store managers, creating a true win-win cooperation.
Malaysia – Customized Touch Display Solutions for Semiconductor Industry
MatsudaPOS supports tailored solutions for advanced industries. For example, we cooperated with SRM Integration (Malaysia) Sdn Bhd, one of the world’s leading providers of semiconductor and high-speed testing processors. We delivered customized touch display equipment that met their unique integration requirements, ensuring seamless collaboration.
Iraq Customer – OEM Packaging Customization
Our long-term partner, Morabaa Sales Point, has worked with MatsudaPOS for over five years. Beyond supplying POS hardware with customized logo printing, we also provide OEM colorful packaging design services. Customers may either rely on our professional design team or supply their own artwork for production.
Taiwan – POSIFLEX Product Customization
POSIFLEX, a globally renowned POS hardware supplier, required a customized solution. In response, MatsudaPOS developed the ST9200F modular POS system, designed to fit their specific demands. Since its launch, the model has gained strong market recognition. We welcome all types of OEM/ODM customization requests from global clients.
Why Choose ST9800?
Superior Dual-Screen Performance
Powered by advanced Intel/Android processors, our POS terminal machines deliver seamless performance, ensuring smooth operations for retail POS systems even during peak business hours.
Space-Optimizing Design
The dual 15-inch touchscreen configuration maximizes workspace efficiency, providing full functionality for retail POS terminals and POS machines, making it perfect for space-conscious retail environments.
Swift Setup and Deployment
Our pre-configured dual-display setup allows for rapid deployment, significantly reducing installation time and accelerating ROI for POS terminal machine implementations.
Robust Commercial Durability
With reinforced metal construction, our POS systems are built to withstand the demands of 24/7 operations in challenging restaurant and retail environments, ensuring long-lasting reliability.
Global Customization Solutions
We offer OEM/ODM services with flexible dual-screen configurations to meet the diverse needs of global POS terminal distributors, ensuring tailored solutions for every market.
Comprehensive Support and Warranty
Enjoy a 3-year warranty and global technical support, ensuring uninterrupted operations for POS machine resellers and system integrators worldwide.
FAQ
Q1: How much does a POS system cost?
Answer: The price depends on your configuration choices such as motherboard, memory, storage, and I/O ports, as well as any customization and order quantity. Please contact us directly for a tailored quotation.
Q2: Can I get a better price?
Answer: Yes. If we establish a long-term partnership, we will definitely offer you competitive wholesale pricing.
Q3. Why are your prices higher than some other suppliers?
Answer: Product quality is our lifeline. We will never cut costs by compromising on quality. Every device is built to last and tested under strict standards.
Q4. This is my first time importing POS equipment in bulk. What should I do?
Answer: Simply contact us. Our sales team will guide you step by step through the entire process. If needed, we can provide door-to-door service from production to delivery.
Q5. Are you a real manufacturer?
Answer: Absolutely. You are welcome to visit our factory at any time. Alternatively, we can arrange a live video call to show you our production facilities.
Q6. What after-sales support do you provide?
Answer: We offer 3 years warranty on POS devices. Our professional engineers are available for remote support to solve any technical issues quickly.
Q7. What are the benefits of becoming a distributor?
Answer: We protect our partners’ interests. Once you become our authorized distributor, we will stop supplying the same product model directly in your region.
Q8. How can I be assured of your product quality?
Answer: We can provide a complete list of component brands and specifications. Quality control and durability testing are conducted on every shipment.
Q9. What is your typical lead time?
Answer: Samples: around 7 days.
Mass production: around 30 days, depending on customization and order volume.
Q10. What payment methods do you accept?
Answer: We accept T/T, L/C, PayPal, and also support ordering via Alibaba International. For other payment options, please contact us directly.
